Description
Technical Specifications
Adduction/Abduction: 0° – 30° – 175°
Internal/External Rotation: 90° – 0° – 90°
Flexion/Extension: 0° – 30° – 175°
Horizontal Adduction/Abduction: 0 – 0 – 125°
Speed: 0 – 100%
Pause: 0 – 30 seconds
Timer: 1 – 300 minutes
Reverse-On-Load: 1 – 20 kp of force* (kp = 2.2 lb. of force)
Warm-Up Mode: 50% of programmed ROM
Therapy Run Time: h : m
Synchronization: On/Off
Motor Control: On/Off
New patient Data Storage
Unit Weight: 55 lb (25 kg)
Dimensions: 34.4″ x 22.6″ x 22.8″ (87.5 cm x 57.5 cm x 58 cm)
Transport Size: 14.6″ x 22.6″ x 22.8″ (37 cm x 57.5 cm x 58 cm)
Safety Tests: CSA – 601-1-M90, UL – 2601-1
Features
-
Easy-to-use hand control for storing treatment data on memory chip card.
-
Fully synchronized motors allow treatment parameters to be customized to meet patient’s specific therapy protocols.
-
Ergonomic armrest and fully adjustable chair.
-
Patented universal left/right adjustable chair.
-
Folds easily for transport/shipping.
-
Lightweight design weighs 55 lbs (25 kg).
